How To Do Well in System Design Interviews?

Key Steps That Matter...

Jan 28, 2025

System design interviews can be intimidating, especially when you're asked to design a scalable, high-performing, and reliable system under time pressure.

These interviews test your ability to break down complex problems, design systems that meet specific requirements, and communicate your thought process effectively.

Here is a 7-step process that can help you do well in your system design interviews:

1 - Requirements Clarification

The first and most critical step is to clarify the system's functional and non-functional requirements. This ensures that you fully understand the problem you’re solving and helps avoid miscommunication later in the process.

You can play around with the diagram on Eraser.io

Key Questions to Ask:

Functional Requirements: What are the core features of the system? For example, in a URL shortener, the ability to create, store, and retrieve short URLs is a core requirement.
Non-Functional Requirements: Ask about performance, scalability, availability, and reliability expectations. Does the system need to handle millions of users? Should it guarantee low latency?

Pro Tip:

Write down the requirements for both parties to refer back to during the discussion. For instance:

Functional: User authentication, real-time updates.
Non-Functional: Low latency (<100ms), 99.99% uptime.

2 - Capacity Estimation

Once the requirements are clear, estimate the system's capacity. This involves understanding the scale at which the system operates.

Typical Metrics to Estimate:

Number of Users: Total users and active users per second.
Traffic: How many requests per second (RPS) will the system handle?
Storage: How much data will the system store daily, monthly, or yearly?
Bandwidth: What is the expected data transfer rate between components?

Example:

If you’re designing a chat application:

Active users: 1M daily active users, 100K concurrent users.
Messages per second: Each user sends 1 message every 10 seconds → 10K messages/second.
Storage: Each message is 1KB → 864GB of messages per day.

3 - Create High-Level Design

Next, create a high-level architecture for the system. Start by breaking it into components and mapping out their interactions.

Steps:

Identify the major components: Client apps, load balancers, application servers, caching layers, databases, etc.
Create a simple block diagram to show how these components interact.
Focus on data flow: How does data travel through the system, from the user to storage and back?

Pro Tip:

Keep the diagram simple at first and add details incrementally as you refine the design.

4 - Database Design

A well-thought-out database design is crucial for most systems. The goal is to choose the right database type and schema to store and retrieve data efficiently.

Steps:

Choose the Database Type:
- Relational (e.g., MySQL, PostgreSQL): For structured data with strict relationships.
- NoSQL (e.g., MongoDB, Cassandra): For unstructured or semi-structured data, or for scalability.
Design the Schema:
- Normalize or denormalize tables depending on query patterns.
- Define primary and secondary indexes for faster lookups.

Example:

In a ride-sharing app, you might use:

Relational DB for user and ride data.
Geospatial indexing for fast location queries.

5 - Interface Design

After database design, focus on interfaces. Define how components interact, including APIs and communication protocols.

Steps:

Identify the APIs:
- Example: For a video streaming service, APIs like /upload, /stream, and /search.
Choose the Communication Protocol:
- REST: For simple, stateless interactions.
- GraphQL: For flexible, client-defined data queries.
- gRPC: For low-latency, high-performance interactions.
Define Data Contracts:
- Specify request and response formats (e.g., JSON, Protobuf).

Why It’s Important:

Well-defined interfaces ensure seamless communication between components.
They act as a contract between services, reducing ambiguity during development.

6 - Scalability and Performance

To meet non-functional requirements like scalability and low latency, you need to address system performance.

Techniques to Consider:

Vertical Scaling: Add more resources (e.g., CPU, RAM) to existing servers.
Horizontal Scaling: Add more servers to handle increased traffic.
Caching:
- Use in-memory stores like Redis or Memcached to reduce database load.
- Cache frequently accessed data, such as user profiles or product catalogs.
Indexing and Denormalization:
- Add indexes to speed up database queries.
- Denormalize data to reduce complex joins.
CDNs:
- Use Content Delivery Networks to serve static assets closer to users.

Why It’s Important:

Scalability ensures the system handles growth without degradation.
Optimizations reduce latency and improve the user experience.

7 - Reliability and Resiliency

Finally, address how your system handles failures to ensure reliability and resiliency.

Strategies:

Identify Single Points of Failure:
- Use redundant load balancers, databases, and servers.
- Replicate data across multiple availability zones or regions.
Resiliency Techniques:
- Implement circuit breakers to prevent cascading failures.
- Use retries with exponential backoff for transient errors.
Data Durability:
- Use backups and snapshots for disaster recovery.
- Ensure data replication and consistency across nodes.
